News
Calculating how large a learning space whiteboard needs to be
Why floor area alone doesn't determine board size
A long, narrow learning space and a wide, shallow one of identical floor area have very different furthest-seat viewing distances, which is the figure that actually drives how large a legible board needs to be, not the total square footage.
This is a common miscalculation in early-stage planning, where floor area is used as a convenient shorthand before a proper sightline assessment has actually been carried out.
Measuring the furthest relevant viewing distance
Identifying the seats genuinely furthest from the board, accounting for both distance and any lateral angle, gives the figure a sizing calculation should actually be based on.
A specific example: in a 200-seat raked learning space, the furthest seat might sit 22 metres from the board in a straight line, but a seat at the extreme side of the same row, only 18 metres away in distance, can actually have a worse effective viewing angle once lateral position is accounted for.
Applying a viewing distance to width ratio
A commonly used guideline suggests board width should be roughly proportional to the furthest viewing distance, though the exact ratio varies depending on text size and how detailed the content typically is.
Suppliers experienced with learning space installations can usually advise on an appropriate ratio for a specific content type, rather than relying on a single generic figure across every project.
Adjusting for content type and detail level
A hall used mainly for diagram-heavy or detailed technical content needs a more generous size relative to viewing distance than one used mainly for brief, large-text prompts.
A specific ratio some universities apply: for detailed technical diagrams with small labelling, board width is sized closer to one-sixth of the furthest viewing distance, compared with roughly one-eighth for simple large-text content, reflecting how much more resolution detailed content actually needs to remain legible.
Confirming the calculation with a practical test
Testing legibility from the calculated furthest seat with sample text at the intended size, before finalising an order, confirms the calculation holds up in practice rather than remaining a theoretical figure.
